Mini-tractor Bl-380
-
Model
BL -380 mini tractor
Certification
CE / ISO9000
Engine
BRIGGES & STRATTON, USA
Power
14.9 kW. (20 hp) at 3600 rev / min
Drive
4x4
Control system
hydraulic, joystick control
Hydraulic system pressure
17.0 MPa
Fuel tank capacity
21 liter
Noise level
less than 95 dB
Cycle time
4.27 from loading . ; Reset to 1.34 . , Unloading 3.31 seconds
Bucket Capacity
200 lbs
Bucket
0.15m ³
Maximum weight for the blade
550 kg
Maximum weight lifting
375 kg
Maximum speed
5.5 km / h
Weight
940 kg
Tyres
Standard 21x8.00-10TR, optionally, lawn tires , skinny tires
Robust design :
Piston type hydraulic machine provides greater torque and all-wheel drive allows the machine to work in a variety of landscapes. Safe , lightweight , shock-resistant platform allows the machine easily to overcome any upgrades.
Multifunctionality :
You can choose more than 20 types of attachments for mini tractors . Attachments has a simple and clear system of attachment , which allows you quickly to switch from one task to another. They are designed for a wide range of works from garden landscaping to work in heavy industries.
Ease of maintenance :
If you have to serve minitractor yourself - it does not take much . When draining the engine oil does not need to crawl under the car , the hole is on the side mini truck in easily accessible place during repairs oil will not be wasted and will not pollute your workspace . For replacement parts upper lid opens easily with a radiator and minimizes maintenance time . There are always plenty of available spare parts, which will not allow technique is simple . The reliable chain drive is too much trouble to repair and last a long time.
Easy to transport :
Tractor BL -380 can be transported by car trailer. Trailer can be adapted to the size of loading and loading conditions . Mounting bracket on the trailer is also a versatile and adapts to any mount.
Dimensions
- Maximum height - 2115 mm
- Dump height: - 1460mm
- The distance from the wheels to bucket: - 185 mm
- Mini tractor height - 1205 mm
- Overall length with bucket - 2206 mm
- Overall length without bucket - 1752 mm
- Bucket width - 980 mm
- Distance till the bucket - 388 mm
- Overall width over tires - 1033 mm
- Ground clearance - 90 mm
- Dump angle at full height - 30 °
- The maximum angle of the bucket from the ground - 25 °
- Turning radius - 1307 mm
